| Model | PowerLite 1771W | PowerLite 1264 | PowerLite 1940W | PowerLite 2155W | PowerLite 2165W | PowerLite 1795F | PowerLite 1284 | PowerLite 2250U | PowerLite 2255U | Model |
| Price | Extended Service Plan |
$1,034  |
|
Price | ||||||
| Brightness | 3000 Lumens | 3200 Lumens | 4200 Lumens | 5000 Lumens | 5500 Lumens | 3200 Lumens | 3200 Lumens | 5000 ANSI Lumens |
5000 ANSI Lumens |
Brightness |
| Contrast Ratio |
2000:1 | 15,000:1 | 3000:1 | 15,000:1 | 15,000:1 | 10,000:1 | 15,000:1 | 15,000:1 | 15,000:1 | Contrast Ratio |
| Native Resolution |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
1080p (1920 x 1080) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
Native Resolution |
| Greatest Displayable Resolution |
UXGA (1600 x 1200) |
UXGA (1600 x 1200) |
UXGA (1600 x 1200) |
1080p (1920 x 1080) |
1080p (1920 x 1080) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
Greatest Displayable Resolution |
| Imaging Technology |
3-LCD | 3-LCD | 3-LCD | 3-LCD | 3-LCD | 3-LCD | 3-LCD | 3-LCD | 3-LCD | Imaging Technology |
| Digital Keystone Correction |
±30° (V) ±30° (H) |
±30° (V) ±30° (H) |
±30° (V) ±30° (H) |
±30° (V) ±20° (H) |
±30° (V) ±20° (H) |
±30° (V) ±20° (H) |
±30° (V) ±30° (H) |
±30° (V) ±20° (H) |
±30° (V) ±20° (H) |
Digital Keystone Correction |
| Lens Shift | No | No | No | No | No | No | No | No | No | Lens Shift |
| Throw Ratio | 1.04 - 1.26:1 | 1.30 - 1.56:1 | 1.51 - 1.99:1 | 1.38 - 2.24:1 | 1.38 - 2.24:1 | 1.02 - 1.23:1 | 1.38 - 1.68:1 | 1.38 - 2.28:1 | 1.57 - 2.58:1 | Throw Ratio |
| Video Inputs | (1) Composite (1) HD-DB15 (1) HDMI |
(1) Composite (1) S-Video (1) Component/ HD-DB15 (1) HDMI |
(1) Composite (2) HD-DB15 (1) HDMI (1) DisplayPort |
(1) Composite (1) HD-DB15 (1) HDMI (1) HDMI/MHL |
(1) Composite (1) HD-DB15 (1) HDMI (1) HDMI/MHL (1) HDBaseT |
(1) Composite (1) Component/ HD-DB15 (1) HDMI |
(1) Composite (1) Component/ HD-DB15 (2) HDMI |
(1) Composite (1) HD-DB15 (2) HDMI |
(1) Composite (1) HD-DB15 (2) HDMI |
Video Inputs |
| Network Connectivity |
Wireless (802.11 b/g/n) |
Optional Wireless (802.11 b/g/n) |
Wired (for Control) |
Wired (for Control) Wireless |
Wired (for Control) Wireless |
Wireless | Optional Wireless (802.11 b/g/n) |
Wired (for control) |
Wired (for control) Wireless (802.11 b/g/n) |
Network Connectivity |
| Native Screen Format |
16:10 | 16:10 | 16:10 | 16:10 | 16:10 | 16:9 | 16:10 | 16:10 | 16:10 | Native Screen Format |
| Supported Screen Formats |
4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | Supported Screen Formats |
| Dimensions (WxHxD) | 11.5" x 2.1" x 8.3" (Including Feet) |
11.7" x 3.2" x 9.2" (Including Feet) |
14.8" x 3.6" x 10.7" (Including Feet) |
14.85" x 4.56" x 11.48" (Including Feet) |
14.85" x 4.56" x 11.48" (Including Feet) |
11.5" x 8.4" x 2.1" (Including Feet) |
11.7" x 3.2" x 9.6" (Including Feet) |
14.85" x 4.93" x 11.48" (Including Feet) |
14.85" x 4.93" x 11.48" (Including Feet) |
Dimensions (WxHxD) |
| Weight | 3.7 Lbs. | 5.29 Lbs. | 8.5 Lbs. | 9.5 Lbs. | 9.5 Lbs. | 4.0 Lbs. | 5.7 Lbs. | 10.2 Lbs. | 10.2 Lbs. | Weight |
| Warranty | 2-Year Limited; 90 Days Lamp Road Service Program |
2-Year Limited; 90 Days Lamp Road Service Program |
2-Year Limited; 90 Days Lamp Road Service Program |
2-Year Limited; 90 Days Lamp |
2-Year Limited; 90 Days Lamp |
2-Year Limited; 90 Days Lamp Road Service Program |
2-Year Limited; 90 Days Lamp Road Service Program |
2 Years Parts & Labor; 90 Days Lamp |
2 Years Parts & Labor; 90 Days Lamp |
Warranty |
| Notes | - | - |
10W Speaker | 16W Speaker Split Screen |
16W Speaker Split Screen |
Miracast® Streaming |
- |
16W Speaker Split Screen |
16W Speaker Split Screen |
Notes |
| Optional Accessories |
- | - | - | - | - | - | - | - | - | Optional Accessories |
| Replacement Items |
Lamp, Filter | Lamp, Filter | Lamp, Filter | - | - | Lamp, Filter | Lamp, Filter | - | - | Replacement Items |
| Model |
PowerLite 1771W | PowerLite 1264 | PowerLite 1940W | PowerLite 2155W | PowerLite 2165W | PowerLite 1795F | PowerLite 1284 | PowerLite 2250U | PowerLite 2255U | Model |
|
