| Model | TX765W | X600 | X605 | W501 | W505 | TW865-NLW/ TW865-NL |
W515/ W515T |
EH503 | EH515/ EH515T |
WU515/ WU515T |
WU630 | ZU850 | WU1500 | Model |
| Price |
$1,169  |
$1,169 |
$2,519 |
TW865-NLW (White Case): TW865-NL (Black Case): $2,696 |
$2,250 |
Price | ||||||||
| Brightness | 4000 ANSI Lumens |
6000 ANSI Lumens |
6000 ANSI Lumens |
5000 ANSI Lumens |
5200 ANSI Lumens |
6000 ANSI Lumens |
6000 ANSI Lumens |
5000 ANSI Lumens |
5500 ANSI Lumens |
6000 ANSI Lumens |
6200 Center 6000 ANSI Lumens |
8000 ANSI Lumens |
12,000 Center 11,000 ANSI Lumens |
Brightness |
| Contrast Ratio |
2500:1 | 10,000:1 | 2000:1 | 15,000:1 | 2000:1 | 4000:1 |
10,000:1 | 2000:1 | 10,000:1 | 10,000:1 | 4,400:1 | 2,000:1 | 5,000:1 | Contrast Ratio |
| Native Resolution |
XGA (1024 x 768) |
XGA (1024 x 768) |
XGA (1024 x 768) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
1080p (1920 x 1080) |
1080p (1920 x 1080) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
Native Resolution |
| Greatest Displayable Resolution |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
HD (1920 x 1080) |
WUXGA (1920 x 1200) |
UXGA (1600 x 1200) |
1080p (1920 x 1080) |
WUXGA (1920 x 1200) |
1080p (1920 x 1080) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
Greatest Displayable Resolution |
| Imaging Technology |
1-Chip DLP™ System (DarkChip™ 2) |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
1-Chip DLP™ System |
Imaging Technology |
| Digital Keystone Correction |
±30° (V) | ±15° (V) | ±30° (V) | ±40° (V) | ±30° (V) | ±20° (V) | ±30° (H) ±30° (V) |
±15° (V) | ±30° (H) ±30° (V) |
±30° (H) ±30° (V) |
±20° (H) ±20° (V) |
±20° (H) ±20° (V) |
±20° (H) ±20° (V) |
Digital Keystone Correction |
| Lens Shift | ±30% (H) | - | ±10% (H) -20% to +100% (V) |
- | ±10% (H) -30% to +50% (V) |
±10% (H) ±50% (V) |
±10% (H) ±20% (V) |
±10% (H) -30% to +50% (V) |
±10% (H) ±20% (V) |
±10% (H) ±20% (V) |
- | ±15% (H) ±50% (V) |
±25% (H) ±60% (V) |
Lens Shift |
| Throw Ratio | 1.62 - 2.64:1 | 1.8 - 2.1:1 | See Lenses | 1.45 - 2.17:1 | See Lenses | See Lenses | 1.26 - 2.268:1 f/stop: 2.3 - 3.39 |
See Lenses | 1.2 - 2.16:1 f/stop: 2.5 - 3.39 |
1.26 - 2.16:1 f/stop: 2.5 - 3.39 |
See Lenses | See Lenses | See Lenses | Throw Ratio |
| Video Inputs | (1) Composite (1) S-Video (2) HD-DB15 (1) DVI-D (1) HDMI |
(1) Composite (1) S-Video (2) HD-DB15 (2) HDMI (1) DisplayPort |
(1) 5-BNC (RGBHV/YPbPr) (1) Composite (1) S-Video (1) Component (2) HD-DB15 (1) DVI-D (1) HDMI |
(1) Composite (1) S-Video (2) HD-DB15 (1) DVI -D (1) HDMI 1.4 |
(1) 5-BNC (RGBHV/YPbPr) (1) Composite (1) S-Video (1) Component (2) HD-DB15 (1) DVI-D (1) HDMI |
(1) 5-BNC (RGBHV/YPbPr) (1) Composite (1) S-Video (1) Component (2) HD-DB15 (1) DVI-D (1) HDMI |
(1) Composite (1) S-Video (2) HD-DB15 (2) HDMI 1.4 (1) DisplayPort *(1) HDBaseT *W515T Only |
(1) 5-BNC (RGBHV/YPbPr) (1) Composite (1) S-Video (1) Component (2) HD-DB15 (1) DVI-D (1) HDMI (1) DisplayPort |
(1) Composite (1) S-Video (2) HD-DB15 (2) HDMI 1.4 (1) DisplayPort *(1) HDBaseT *EH515T Only |
(1) Composite (1) S-Video (2) HD-DB15 (2) HDMI 1.4 (1) DisplayPort *(1) HDBaseT *WU515T Only |
(1) 5-BNC (RGBHV/YPbPr) (1) Composite (1) HD-DB15 (1) DVI (1) HDMI 1.3a (3D Support) |
(1) Component (1) HD-DB15 (1) DVI-D (1) HDMI 1.4 (1) HDBaseT (1) 3G-SDI |
(1) 5-BNC (RGBHV/YPbPr) (1) S-Video (1) HD-DB15 (1) DVI-D (1) HDMI (1) HDBaseT (1) 3G-SDI |
Video Inputs |
| Network Connectivity |
Wired (for Control) Wireless - 802.11b/g (for Imaging) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Wired (for Control) |
Network Connectivity |
| Native Screen Format |
4:3 | 4:3 | 4:3 | 16:10 | 16:10 | 16:10 | 16:10 | 16:9 | 16:9 | 16:10 | 16:10 | 16:10 | 16:10 | Native Screen Format |
| Supported Screen Formats |
4:3, 16:9. 16:10 | 4:3, 16:9; 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | 4:3, 16:9, 16:10 | Supported Screen Formats |
| Dimensions (WxDxH) | 14.3" x 5" x 11.1" | 12.8" x 4.3" x 10.2" | 16.9" x 7.1" x 13.4" | 15.2" x 6" x 11" | 16.9" x 7.1" x 13.4" | 21.3" x 7.8" x 16.5" | 16.7" x 13.5" x 6.3" | 16.9" x 7.1" x 13.4" | 16.7" x 13.5" x 6.3" | 16.7" x 13.5" x 6.3" | 17.8" x 8.1" x 15.3" | 19” x 7.7” x 20.7” | 23.3" x 8.2" x 20.5" | Dimensions (WxDxH) |
| Weight | 12 Lbs. | 8.2 Lbs. | 18.9 Lbs. | 9.9 Lbs. | 18.9 Lbs. | 40.3 Lbs. | 13 Lbs. | 18.6 Lbs. | 13 Lbs. | 13 Lbs. | 31 Lbs. | 50.7 Lbs. | 51 Lbs. | Weight |
| Warranty | 3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
3 Years Parts & Labor Express Replacement |
3 Years Parts & Labor Express Replacement |
3 Years Parts & Labor 1 Year Lamp Express Replacement |
Warranty |
| Notes | 12V Trigger | 3D Compatibility 12V Trigger |
3D Compatibility 12V Trigger 3W Speaker (x2) Lens not Included |
12V Trigger 15W Speaker (x2) |
3D Compatibility 12V Trigger 3W Speaker (x2) Lens not Included |
3D Compatibility 360° Orientation 24/7 Operation Lens not Included |
3D Compatibility 4-Corner Geometric Correction 10W Speaker (x2) |
3D Compatibility 12V Trigger 3W Speaker (x2) DICOM Simulation Mode Lens not Included |
3D Compatibility 4-Corner Geometric Correction 10W Speaker (x2) |
3D Compatibility 4-Corner Geometric Correction 10W Speaker (x2) |
Lens not Included | Lamp-Free Design (via Laser Phospher Technology) 360° Projection Portrait Mode Lens not Included |
Edge Blending Warping Black Level Correction 360° Projection Portrait Mode Lens not Included |
Notes |
| Optional Accessories |
Ceiling Mount | Ceiling Mount 3D Glasses |
Lenses 3D Glasses |
Ceiling Mount | Ceiling Mount Lenses 3D Glasses |
Ceiling Mount Lenses 3D Glasses |
3D Glasses | Ceiling Mount Lenses 3D Glasses |
3D Glasses | 3D Glasses | Lenses | Lenses 3D Glasses |
Lenses 3D Glasses |
Optional Accessories |
| Replacement Items |
Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | Lamp, Remote | - | Lamp | Replacement Items |
| Links |
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Links | ||
Model |
TX765W | X600 | X605 | W501 | W505 | TW865-NLW/ TW865-NL |
W515/ W515T |
EH503 | EH515/ EH515T |
WU515/ WU515T |
WU630 | ZU850 | WU1500 | Model |
|
