Optoma ZU920TST

Ultra-Bright fixed lens laser projector

At 9,800 lumens (8200 ANSI lumens) with 4K and HDR compatibility, the Optoma ZU920TST features a dust-resistant IP5X certified optical engine for 24/7 operation, offering true maintenance-free projection for up to 30,000 hours of powerful performance in Eco mode.

This WUXGA laser projector also features motorized zoom, full motorized lens shift, and built-in dual 10W speakers.

High brightness, color precision and quiet operation, along with a short-throw lens, make the ZU920TST professional laser projector the ideal solution for a variety of end-user scenarios and professional environments, such as short-throw digital signage, edge-blending and projection mapping, simulation, and immersive installations.

The added control flexibility of HDBaseT and LAN makes this Optoma projector an affordable install-and-forget solution.

Key Features:

• Ultra bright 9,800-lumen DuraCore laser for immersive installations

• Full motorized lens shift — ideal for a simple setup

• Large motorized zoom range expands placement opportunities

• 30,000 hours of virtually maintenance-free operation

• Fixed lens laser projector design

• DuraCore: Industry-leading lifetime is achieved using Optoma’s DuraCore technology, implementing advanced laser diode cooling techniques and an innovative dust-resistant design.

• Full lens shift: Simplify installation with full lens shift, which provides a wider range of projector placement possibilities. This makes it easier to position the projector in your room and enables a wider range of screen size options.

• Four corner correction: Adjust the keystone in both the vertical and horizontal plane. You can individually warp each corner of the image to create a perfectly square image. Ideal for image stacking, uneven walls, or where projector placement is awkward, requiring installation at an angle.

• IP5X Dust resistant optical engine: Independently tested and certified to IEC standard 60529 with an IP5X dust resistance rating. Outstanding dust resistance combined with exceptional brightness ensures industry-leading durability, ideal for 24/7 maintenance-free operation in challenging environments.

• HDBaseT™: Uncompromising, uncompressed Full HD video, audio, network and control commands all delivered on a single CAT-type cable, from up to 100 meters/328 feet without signal loss, make installation hassle-free. HDBaseT™ simplifies cabling requirements and reduces installation complexity, saving time and reducing costs.

• HDR compatible: Capable of receiving and displaying HDR meta data, Optoma HDR-compatible projectors allow you to see far more detail and texture. Objects look more solid and lifelike, and the extra detail creates a greater sense of depth. It's like looking through a window.

• Portrait projection: rotate your projector 90 degrees to project a portrait image, ideal for digital signage applications.

• 360 projection: Images can be projected over a 360° range along the projector's horizontal axis. (See User Manual for details.)

• Integrated warping and edge blending processor: enables multiple projectors to be warped and blended without additional dedicated hardware, reducing the cost and complexity of installation. Warping and edge blending is configured using either the projector's on-screen display or with PC software, depending on the model. (Compatible multi-output graphics card with overlap function is required.)

• Color Management System (CMS): Display accurate lifelike colors to best match your viewing environment. This unique feature provides the flexibility to fine-tune the color settings for optimal precision.

• True AV mute: enables the light source of the projector to be instantly switched off and on at the press of a button. Unlike standard AV mute functionality, no light is emitted from the projector, giving 100% blackout on screen.

• Full 3D: can display true 3D content from almost any 3D source, including 3D-compatible graphics cards, 3D broadcasting and the latest generation 3D media servers.

• Wired remote: The wired remote connection allows all aspects of the projector to be individually controlled without requiring a line-of-sight to the projector — invaluable when using multiple units during live events.

• Direct power off: Power off your projector immediately or directly at the mains. This means you don’t have to wait for the projector to cool down before turning it off.

• Constant power: Allows users to set the power levels to meet individual installation requirements. Power levels can be managed to obtain the brightest picture, longest light source life, or anywhere in between.

• Constant brightness: Advanced light-sensing technology allows the setting of brightness levels that will remain unchanged over time. Ideal for ensuring constant brightness for long-running installations.

• Telnet: This model is able to receive commands via telnet, allowing for easy installation with Telnet-compatible control systems.

• Control: a wide range of options let you control and monitor the projector remotely:
  • RS232 Optoma projectors come with an extensive set of RS232 commands, making it simple and easy to manage using any control system.
  • AMX Compatibility Dynamic discovery protocol is incorporated into the projector allowing for easy installation with AMX control systems.
  • Crestron RoomView^® software lets you power on/off, monitor, manage and control up to 250 projectors at the same time from any computer
  • Extron IPLink-compatible allows for easy installation with Extron control systems

Warranty

• 3-year parts and labor limited warranty on the projector with first year express advance replacement
• 5-year or 12,000 hour light source warranty (whichever comes first)
