| Model | PGXG-61B | PHXG-91B | PFWX-51B | PGWX-62L | PGWX-61B | PHWX-81B | PFWU-51B | PGWU-61B | PGWU-62L | PJWU-101B | RLS-W12 | RLM-W8 | MSWU-81E | |
| List Price |
$1,799  |
$3,089 |
$1,481 |
$3,200 |
$2,135 |
$2,999 |
$2,499 |
$2,975 |
$8,649 |
Call or Email for Price | $9,995 |
List Price | ||
| Brightness | 6750 Lumens | 8500 Lumens | 4750 Lumens | 6000 Lumens | 6200 Lumens | 7300 Lumens | 4650 Lumens | 5900 Lumens | 6000 Lumens | 11,000 Lumens | 11,000 Lumens | 8000 Lumens | 8300 Lumens | Brightness |
| Contrast Ratio |
1100:1 | 1600:1 | 1800:1 | 11,000:1 | 1100:1 | 1850:1 | 1800:1 | 1100:1 | 11,000:1 | 1250:1 | 1500:1 | 2200:1 | 1800:1 | Contrast Ratio |
| Native Resolution |
XGA (1024 x 768) |
XGA (1024 x 768) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WXGA (1280 x 800) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
WUXGA (1920 x 1200) |
Native Resolution |
| Imaging Technology |
1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1-Chip DLP | 1- Chip DLP | 3 x 0.67” Chip DLP | 3 x 0.67” Chip DLP | Imaging Technology |
| Lens Shift | -100% to +100% (V) -28% to +28% (H) |
-0% to +118% (V) -20% to +20% (H) |
-30% to +110% (V) -10% to +10% (H) |
-100% to +100% (V) -30% to +30% (H) |
-100% to +100% (V) -28% to +28% (H) |
-0% to +134% (V) -20% to +20% (H) |
-30% to +110% (V) -10% to +10% (H) |
-100% to +100% (V) -28% to +28% (H) |
-100% to +100% (V) -30% to +30% (H) |
H & V | H & V | ±30% H ±100% V |
±30% H ±100% V |
Lens Shift |
| Throw Ratio | See Lenses | 1.7 - 2.4:1 Other Lenses Avail. |
1.62 - 2.03:1 Other Lenses Avail. |
See Lenses | See Lenses | 1.73 - 2.44:1 Other Lenses Avail. |
1.54 - 1.93:1 Other Lenses Avail. |
See Lenses | See Lenses | See Lenses | See Lenses | See Lenses | See Lenses | Throw Ratio |
| Video Inputs | HD-DB15 DVI-D HDMI 1.3 |
5-BNC RGBHV S-Video HD-DB15 DVI-D HDMI |
5-BNC RGBHV Composite S-Video Component (2) HD-DB15 DVI-I HDMI 1.3 DisplayPort |
Composite HD-DB15 DVI HDMI |
HD-DB15 DVI-D HDMI 1.3 |
5-BNC RGBHV S-Video HD-DB15 DVI-D HDMI |
5-BNC RGBHV Composite S-Video Component (2) HD-DB15 DVI-I HDMI 1.3 DisplayPort |
HD-DB15 DVI-D HDMI 1.3 |
Composite HD-DB15 DVI HDMI |
5-BNC RGBHV HD-DB15 (2) HDMI |
5-BNC RGBHV HD-DB15 HDMI HSDI/3G HDSDI/SDI HDBaseT BarcoLink |
(2) HDMI 3G/HD/SD-SDI 5-BNC (RGBHV or YPbPr) HD-DB15 Composite Video S-Video BarcoLink |
5-BNC RGBHV HD-DB15 (2) HDMI |
Video Inputs |
| Network Connectivity |
Wired | Wired | Wired | Wired | Wired |
Wired | Wired | Wired | Wired | Wired | Wired | Wired | Wired | Network Connectivity |
| Native Screen Format |
4:3 | 4:3 | 16:10 | 16:10 | 16:10 | 16:10 | 16:10 | 16:10 | 16:10 | 2048:1080 | 16:10 | 16:10 | 16:10 | Native Screen Format |
| Dimensions (WxLxH) |
18.7" x 22.24" x 9.98" | 10.63" x 19.69" x 24.84" | 18.11" x 17.56" x 8.23" | 19.92" x 20.31" x 9.88" | 18.7" x 22.24" x 9.98" | 20.08" x 25.98" x 10.35" | 18.11" x 17.56" x 8.23" | 18.7" x 22.24" x 9.98" | 19.92" x 20.31" x 9.88" | 26.38" x 20.87" x 11.22" | 20.86" x 32.64" x 17.2" | 9.72" x 19.69" x 26.36" | 10.4" x 26.4" x 20.9" | Dimensions (WxLxH) |
| Weight | 37.5 Lbs. | 46.3 Lbs. | 26.5 Lbs. | 38.58 Lbs. | 37.5 Lbs. | 46.3 Lbs. | 26.5 Lbs. | 37.5 Lbs. | 38.58 Lbs. | 72.75 Lbs. | 74.95 Lbs. | 57.3 Lbs. | 71.7 Lbs. | Weight |
| Warranty | 3 Years Standard |
3 Years Standard |
3 Years Standard | 3 Years Standard | 3 Years Standard | 3 Years Standard | 3 Years Standard | 3 Years Standard | 3 Years Standard | 3 Years Standard | 3 Years Standard | 3 Years Standard |
3 Years Standard | Warranty |
| Notes | 3D Ready Keystone Correction |
ScenergiX WARP Integrated Web Server Keystone Correction |
3D Ready Integrated Web Server Keystone Correction |
3D Ready Integrated Web Server Keystone Correction Laser Light Source |
3D Ready Keystone Correction |
ScenergiX WARP Integrated Web Server Keystone Correction |
3D Ready Integrated Web Server Keystone Correction |
Keystone Correction | 3D Ready Integrated Web Server Keystone Correction Laser Light Source |
Integrated Web Server Keystone Correction |
Edge Blending Warping 12V Trigger |
Edge Blending Warping 12V Trigger |
Keystone Correction | Notes |
| Optional Accessories |
Lenses ClickShare |
Lenses ClickShare |
Lenses ClickShare |
Lenses ClickShare |
Lenses ClickShare |
Lenses ClickShare |
Lenses ClickShare |
Lenses ClickShare |
Lenses ClickShare |
Lenses | Lenses | Lenses | Lenses | Optional Accessories |
| Replacement Items |
Lamp, Filter | Lamp | Lamp | - | Lamp, Filter | Lamp | Lamp | Lamp, Filter | - | Lamp, Filter | Lamp, Filter | Lamps, Filters | Lamp, Filter | Replacement Items |
| Links |
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
Technical Docs
|
BarcoLink  Technical Docs
|
BarcoLink |
Technical Docs
|
Links |
 |
PGXG-61B | PHXG-91B | PFWX-51B | PGWX-62L | PGWX-61B | PHWX-81B | PFWU-51B | PGWU-61B | PGWU-62L | PJWU-101B | RLS-W12 | RLM-W8 | MSWU-81E | |
|
